SKU: BA15-35098
8.2FT Black Type B Japanese Power JIS8303 to IEC320 C15 7A 125V
Japan 15A JIS8303 (5-15P) to C15 Power Cords
BA15-35098
Per unit · USD
Volume pricing
| Quantity | Unit price | Savings |
|---|---|---|
| 1–99 | $14.62 | List price |
| 100–249 | $13.46 | Save 8% |
| 250–499 | $11.70 | Save 20% |
| 500+ | $10.23 | Save 30% |
Need a different length, gauge, or connector?Build a custom cord →
Currently out of stock
Get notified the moment 8.2FT Black Type B Japanese Power JIS8303 to IEC320 C15 7A 125V is back.
One email when restocked. No marketing — unsubscribe link included.
B2B & OEM services
✓Volume pricing & NET terms — breaks start at 10 units
✓BOM partner for OEMs — we work from your spec sheet
✓Approvals expert — UL, CSA, CE, RoHS support available
Hi-pot tested
Every cord we build is hi-pot and continuity tested.
Engineering-led
In-house engineering and compliance set the procedures.
Ships same day
In-stock orders out of East Windsor, CT before 3pm ET.
30-day returns
Plus lifetime workmanship warranty.
| Current (Amps) | 12 Amps |
| Voltage (Volts) | 125 volts |
| Cordage | 1.25mm2 -3c VCTF |
| Certifications | RoHS |
| Approvals | PSE |
| Approvals | JET |
| Plug (Male) | Japan JIS8303 3-Pin 5-15P |
| Connector (Female) | IEC 60320 C15 |
| Length | 2.5 meters |
| Color | Black |
Certifications & Compliance
About this product
Japan JIS C 8303 (5-15P) Power Cords, Class I standard, 3-pin grounded. The plug looks the same as the North America 5-15P. The dimensional tolerances are more strict for the Japan plug. A North American plug may not fit into an outlet for Japan because of the tolerance differences. Manufactured with PSE approvals. Typical cordage uses VCTF/HVCTF/VCTFK jacket material. VCTF has a round shape and is rated to 60C. HVCTF has a round shape and is rated to 75C. VCTFK has an oval shape and is rated 60C.
Length
| 2.5 meters | 2.5 meters |
Current (Amps)
| 12 Amps | 12 Amps |
Voltage (Volts)
| 125 volts | 125 volts |
Connector (Female)
| IEC 60320 C15 | IEC 60320 C15 |
Plug (Male)
| Japan JIS8303 3-Pin 5-15P | Japan JIS8303 3-Pin 5-15P |
Cordage
| 1.25mm2 -3c VCTF | 1.25mm2 -3c VCTF |
Approvals
| PSE | PSE |
| JET | JET |
Certifications
| RoHS | RoHS |
Color
| Black | Black |
Physical
| weight lbs | 0.95 |
- Download PDF
Spec sheet (PDF)
Generated specification sheet for this part number
No alternate configurations available.
Typical Application
Power source
Japan JIS8303 3-Pin 5-15P plug
2.5 meters Black
Powered equipment
C15 connector
Connects a Japan JIS8303 3-Pin 5-15P source to a C15 device inlet. Rated 12 Amps at 125 volts.
Countries of Application
| Country | Approval |
|---|---|
| Japan | JP |
