SKU: 515-L515-H-012
1FT Black Adapter NEMA 5-15P to NEMA L5-15R 15A 125V
Black NEMA 5-15P to Locking L5-15R Straight to Locking Adapter Cords
515-L515-H-012
Per unit · USD
In stock (198 available)
Order by 2:30 PM ET and it ships today.
Need a different length, gauge, or connector?Request a custom quote →
Volume pricing
| Quantity | Unit price | Savings |
|---|---|---|
| 1–99 | $16.13 | List price |
| 100–249 | $14.52 | Save 10% |
| 250–499 | $12.90 | Save 20% |
| 500+ | $11.29 | Save 30% |
Buying more than 500, or need a better price? Call (860) 763-2100 or e-mail sales@worldcordsets.com — we quote volume pricing every day.
B2B & OEM services
✓Volume pricing & NET terms — breaks start at 10 units
✓BOM partner for OEMs — we work from your spec sheet
✓Approvals expert — UL, CSA, CE, RoHS support available
Hi-pot tested
Every cord we build is hi-pot and continuity tested.
Engineering-led
In-house engineering and compliance set the procedures.
Ships same day
In-stock orders out of East Windsor, CT before 2:30 PM ET.
30-day returns
Plus lifetime workmanship warranty.
Certifications & Compliance
About this product
1FT NEMA 5-15P to L5-15R 15A 125V 14awg-3c SJT Adapter Cord - BLACK. Converts a twist-lock NEMA L5-15P into a straight blade NEMA 5-15P
The NEMA 5-15P is a 3 Wire grounded plug featuring two blades (can be equal or unequal widths due to the ground pin forcing polarity) and one ground pin rated up to 125V AC and 15 Amps. The NEMA 5-15P is your standard household plug used for to connect small appliances such as TV's, Microwaves, hairdryers, etc to a wall outlet. The NEMA 5-15P is compatible with a Nema 5-20R T-Slot outlet, which is commonly found in new home installations.
The NEMA L5-15R is a 3 Wire 3 Blade grounded connector featuring 3 Blades arranged in a tight circular pattern rated up to 125V AC and 15 Amps. The plug locks to the connector by twisting into place. Locking cords are typically used in industrial applications to ensure that accidental power loss does not occur due to a loose connection.
Specifications
| Plug (Male) | NEMA 5-15P |
| Connector (Female) | NEMA L5-15R |
| Current (Amps) | 15 Amps |
| Voltage (Volts) | 125 volts |
| Cordage | 14awg-3c SJT |
| Length | 1 Foot |
| Color | Black |
| Certifications | RoHS, REACH |
| Approvals | UL, cUL |
Physical
| weight lbs | 0.25 |
- Download PDF
Spec sheet (PDF)
Specification sheet for this part number — opens the PDF, or lets you request a drawing from engineering when one is not on file yet
No alternate configurations available.
Typical Application
Connects a NEMA 5-15P source to a NEMA L5-15R device inlet. Rated 15 Amps at 125 volts.
Countries of Application
| Country | Approval |
|---|---|
| United States | US |
| Mexico | MX |
| Canada | CA |
Our commitment: In-stock cords ship the same day when ordered by 2:30 PM ET. If it doesn't meet spec, we replace it and pay return shipping. Questions during installation? Same number as sales — a real engineer picks up.
