Black Type B Japanese Power JIS8303 to IEC320 C5 7A 125V
Reference guide:IEC 60320 connector guide →
1
configurations
About Black Type B Japanese Power JIS8303 to IEC320 C5 7A 125V
Japan 15A JIS8303 (5-15P) to C5 Power Cords are used to connect a grounded smaller device to a standard Japanese Wall outlet.
The plugs and connectors in this collection
What each end is, what it mates with, and where to find every cord built on it.
Connector · IEC 60320
IEC 60320 C5
- 10 Amps
- 250 volts
On 1 of the cords here
The IEC 60320 C5 is a grounded 3 Wire connector rated up to 250V and 2.5 Amps Internationally or 125V and 10 Amps in North America. The C5 mates with a C6 inlet, and is commonly used for laptop power supplies, projectors, and some televisions. Being slightly smaller in size than the C13, the C5 can be a good choice for smaller appliances. This connector is sometimes referred to as a "Mickey Mouse" connector due to the shape of the connector looking similar to the kids television show character.
Mates with IEC 60320 C6 Inlet
Plug · International
Japan JIS8303 3-Pin 5-15P
- 15 Amps
- 125 volts
On 1 of the cords here
The Japan JIS8303 3-Pin plug configuration is rated for 125VAC and 15 Amperes in Japan. The design is known as IEC Type B and is nearly identical to the United States version NEMA 5-15P, with the exception of having different global electrical approvals. This is the standard plug type in Japan for household power.
Mates with JIS8303 3-Pin Outlet
About Black Type B Japanese Power JIS8303 to IEC320 C5 7A 125V
World Cord Sets supplies black type b japanese power jis8303 to iec320 c5 7a 125v from our East Windsor, Connecticut headquarters, with manufacturing across US and overseas facilities. Cords are tested and certified to spec before shipment. We stock 1+ configurations and build custom cords to order — hand-terminated builds from in-stock components typically ship in 3–4 business days. In-stock orders placed by 2:30 PM ET ship the same day from our Connecticut warehouse.
Current rating
7 Amps
Voltage rating
125 volts
Plug (male end)
Japan JIS8303 3-Pin 5-15P
Connector (female end)
IEC 60320 C5
Certifications & compliance
- PSE
- JET
- RoHS
- Every cord we build is hi-pot tested
- Same-day shipping by 2:30 PM ET
- NET 30/60/90 for approved accounts
- In-house engineering and compliance support
